Compatible selective wave solder S nozzle 2.7/5.5 mm H=47 B22, reference part number 296788.

Product Image

Quick Specification Answer

Reference 296788 is a Standard compatible selective soldering nozzle with ID/AD 2.7/5.5, height H=47, base B22. Compatibility and quote status require confirmation against the drawing and equipment configuration.

296788 Compatible Selective Soldering Nozzle for Ersa, 2.7/5.5 mm, H=47, B22

Name: Selective Wave Solder S Nozzle 2.7/5.5mm H=47 B22 296788 for Ersa
SKU: 296788

Compatible Aftermarket New

Engineering Specifications

Reference PN

296788

ID / AD

2.7/5.5

Height

H=47

Base

B22

MOQ

1 pc

Lead Time

Availability and lead time are subject to confirmation.

Shipping

DHL / FedEx / UPS / TNT / Air Freight

WhatsApp Aero

Send Old Nozzle Photo Request Custom Size Part Number Lookup Ask Aero for the latest product or batch photo

Compatibility Notice: This is an aftermarket compatible replacement part. Brand names are used only to indicate machine compatibility.

This S Nozzle 2.7/5.5mm H=47 is an aftermarket compatible replacement nozzle for Ersa selective soldering machines. It is designed for selective wave soldering applications that require stable solder flow, heat resistance and precise wetting performance. Reference part number: 296788. Custom sizes and drawings can also be supported.

Product Type	Selective Soldering S Nozzle
Compatible Brand	Ersa
Reference Part Number	296788
ID / AD (Inner/Outer Diameter)	2.7/5.5 mm
Nozzle Height	H=47
Base / Solder Pot Type	B22
Nozzle Type	Standard
Condition	Compatible New / Aftermarket New
MOQ	1 pc
Lead Time	Availability and lead time are subject to confirmation.
Shipping	DHL / FedEx / UPS / TNT / Air Freight
Customization	Available by drawing or sample
Compatibility Notice	This is an aftermarket compatible replacement part. Brand names are used only to indicate machine compatibility.
